Pine Energy (Shenzhen)co., Ltd maintains stringent norms of quality to manufacture Wall Mounted Solar Energy Storage Battery 48v 51.2v 100ah 200ah 5kwh 10kwh Lithium Ion Lifepo4 Batteries Powerwall. The Lithium Ion Batteries product will supply to all over the world, such as Europe, America, Australia,Uganda , Oman ,Sri Lanka , Surabaya . Therefore, for those buyers looking to buy Wall Mounted Solar Energy Storage Battery 48v 51.2v 100ah 200ah 5kwh 10kwh Lithium Ion Lifepo4 Batteries Powerwall in bulk quantity for their business, buying them from a reputable manufacturer would be a wise choice.
Brand Name | PINE | Model Number | PN-LP-48100H |
Battery Size | 18650 | Place of Origin | Guangdong, China |
Weight | 103KG | The charging ratio | 100A |
The discharge rate | 100% DOD | Storage Type | Battery energy storage |
Warranty | 5years | Anode Material | LFP |
Application | Power Tools, Home Appliances, Consumer Electronics, BOATS, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Solar Energy Storage Systems, Uninterruptible Power Supplies, Telecom /UPS/Solar Energy Storage | Product name | 5kwh powerwall battery |
Battery type | LifePo4 | Apllication | UPS/Energy storage, Home Appliances, Solar Energy Storage System |
Cycle life | 6000 Cycles | Case Material | SPCC |
Features | deep cycle | Capacity | 100Ah |
Keywords | 5Kwh powerwall battery | battery type | lithium ion battery |
Shipping Classification | UN3480,CLASS9 | Chargeable | Yes |
Certification | CE[Battery], UN38.3[Battery] IEC62133[cell] |
Electrical Specification | Mechanical Specifications | ||||
Nominal Voltage: | 48V | Dimensions: | 680*485*180mm | ||
Nominal Capacity | 200Ah | Weight: | 68KG | ||
Capacity @20A | 300min | Terminal Type: | RS485&RS232 | ||
Energy | 4800Wh | Case Material: | SPCC | ||
Resistance | ≤30mΩ @ 50% SOC | Enclosure Protection: | IP20 | ||
Efficiency: | 99% | Cell Type: | Prismatic | ||
Self Discharge | ≤3.5% Per Month | Chemistry: | LifePo4 | ||
Maximum Modules in series of Parallel: | 15 | Configuration: | 15S4P |
Discharge Specifications | Charge Specifications | ||||
Maximum Continuous Discharge Current | 100A | Recommend Charge Current | 5A-40A | ||
Peak Discharge Current | ≤150A | Maximum Charge Current | 50A | ||
BMS Discharge Current Cut-off | 130A±20A [90±10ms] | Recommed Charge Voltage | 52.5-54V | ||
Recommend Low Voltage Disconnect | 42V | BMS Charge Voltage Cut-off | 54V[3.75±0.1V] | ||
BMS Discharge Voltage Cut-off | 42V[2.8±0.08 vpc] [100±50ms] | Reconnect Voltage | 51.8V[3.45±0.1V] | ||
Reconnect Voltage | 10V[2.5±0.1vpc] | Balancing Voltage | 52.5V[3.5±0.025vpc] | ||
Short Circuit Protection | 200-400μs | Balancing Current | 35±5mA |
Temperature Specifications | ||
Discharge Temperature | -4 to 140℉[-20 to 60℃] | |
Charge Temperature | 32 to 113℉[0 to 45℃] | |
Storage Temperature | 23 to 113℉[-5 to 45℃] | |
BMS High Temperature cut-off Discharge | 149℉[65℃][Customized] | |
Reconnect Temperature | 122℉[50℃][Customized] | |
Low Temperature Cut-off Charge | 32℉[0℃][Customized] | |
High Temperature Cut-off Charge | 129.2℉[54℃][Customized] |
