Pine - Best Seller Rechargeable Lifepo4 Battery 48v 120ah Lithium Iron Phosphate Batteries For Camping 24V Lifepo4 battery compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.Pine summarizes the defects of past products, and continuously improves them. The specifications of Pine - Best Seller Rechargeable Lifepo4 Battery 48v 120ah Lithium Iron Phosphate Batteries For Camping 24V Lifepo4 battery can be customized according to your needs.
Best Pine - Best Seller Rechargeable Lifepo4 Battery 48v 120ah Lithium Iron Phosphate Batteries For Camping 24V Lifepo4 batteryPine compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.Pine summarizes the defects of past products, and continuously improves them. The specifications of Best Pine - Best Seller Rechargeable Lifepo4 Battery 48v 120ah Lithium Iron Phosphate Batteries For Camping 24V Lifepo4 batteryPine can be customized according to your needs.
Technology advancement ensures our leading position in the industry. We have been unswervingly updating and developing technologies. It is the utilization of high-end technologies that ensures the product properties are fully played out.Field(s) of Lithium Ion Batteries have proved its superiority.
With experienced, professional, and well-educated employees,Pine Energy (Shenzhen)co., Ltd is efficient and excellent in developing products, one of which is Best Seller Rechargeable Lifepo4 Battery 48v 120ah Lithium Iron Phosphate Batteries For Camping. It has some unique features. High-quality Best Seller Rechargeable Lifepo4 Battery 48v 120ah Lithium Iron Phosphate Batteries For Camping rely on strong research and development capabilities and a good brand image. Get in touch with us - call, fill in our online form or connect via live chat, we are always happy to help.
| Brand Name | PINE | Model Number | PN-LP-24100 |
| Battery Size | 18650 | Place of Origin | China |
| Weight | 20KG | Warranty | 5years |
| Anode Material | LFP | Application | Solar Energy Storage Systems |
| Product name | Lithium Battery | Chemistry | LifePo4 |
| Configuration | 8S1P | Case Material | ABS |
| Enclosure Protection | IP65 | Short Circuit Protection | 200-400μs |
| Low Temperature Cut-off Charge | 32℉[0℃][Customized] | High Temperature Cut-off Charge | 129.2℉[54℃][Customized] |
| Shipping Classification | UN3480,CLASS9 | Chargeable | Yes |
| Certification | CE[Battery], UN38.3[Battery] IEC62133[cell] |
Electrical Specification | Mechanical Specifications | ||||
Nominal Voltage: | 25.6V | Dimensions(L*W*H): | 486*170*240mm | ||
Nominal Capacity | 100Ah | Weight: | 20KG | ||
Capacity @50A | 120min | Terminal Type: | M8/M6 | ||
Energy | 2560Wh | Case Material: | ABS | ||
Resistance | ≤30mΩ @ 50% SOC | Enclosure Protection: | IP65 | ||
Efficiency: | 99% | Cell Type: | Prismatic | ||
Self Discharge | ≤3.5% Per Month | Chemistry: | LifePo4 | ||
Maximum Modules in series of Parallel: | 8 | Configuration: | 8S1P | ||
Discharge Specifications | Charge Specifications | ||||
Maximum Continuous Discharge Current | 100A | Recommend Charge Current | 5A-50A | ||
Peak Discharge Current | 260A≤5s | Maximum Charge Current | 100A | ||
BMS Discharge Current Cut-off | 300A±20A [2.2±1ms] | Recommed Charge Voltage | 28.4-29.2V | ||
Recommend Low Voltage Disconnect | 17.6V | BMS Charge Voltage Cut-off | 30V[3.75±0.1V] | ||
BMS Discharge Voltage Cut-off | 17.6V[2.2±0.08 vpc] [100±50ms] | Reconnect Voltage | 29.2V[3.65±0.1V] | ||
Reconnect Voltage | 20V[2.5±0.1vpc] | Balancing Voltage | 28.0V[3.5±0.025vpc] | ||
Short Circuit Protection | 200-400μs | Balancing Current | 35±5mA | ||
Temperature Specifications | ||
Discharge Temperature | -4 to 140℉[-20 to 60℃] | |
Charge Temperature | 32 to 113℉[0 to 45℃] | |
Storage Temperature | -4 to 113℉[-20 to 45℃] | |
BMS High Temperature cut-off Discharge | 149℉[65℃][Customized] | |
Reconnect Temperature | 122℉[50℃][Customized] | |
Low Temperature Cut-off Charge | 32℉[0℃][Customized] | |
High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | |
