Pine is a professional solar product supplier, lithium ion battery manufacturer and solar energy system factory in China.
Language
Pine is a professional solar product supplier, lithium ion battery manufacturer and solar energy system factory in China.
Under the instruction of senior engineers and high-level technicians, our R&D employees worked hard to improve technologies, therefore making the manufacturing process more efficient. In the field(s) of Safe Shipment 48v 150ah Lithium Iron Phosphate Battery Deep Cycle Lipo Lifepo4 Lithium Ion Li Ion Telecom Battery Pack, the product is highly recognized.
We feature a broad range of hi-quality Safe Shipment 48v 150ah Lithium Iron Phosphate Battery Deep Cycle Lipo Lifepo4 Lithium Ion Li Ion Telecom Battery Pack for peolpe of all age group. Safe Shipment 48v 150ah Lithium Iron Phosphate Battery Deep Cycle Lipo Lifepo4 Lithium Ion Li Ion Telecom Battery Pack can bring greater value to customers and help customers gain a firm foothold in the complex market environment. Combining all good performance of adopted raw materials, our Safe Shipment 48v 150ah Lithium Iron Phosphate Battery Deep Cycle Lipo Lifepo4 Lithium Ion Li Ion Telecom Battery Pack has been proved to be applied to the field(s) of Lithium Ion Batteries.Our staff has tested multiple times that in the applied fields, the product can give out its best performance such as durability and stability.
| Brand Name | PINE | Model Number | PN3500 |
| Battery Size | 18650 | Place of Origin | China |
| Weight | 70KGS | Storage Type | high capacity storage battery |
| Warranty | 5years | Anode Material | LFP |
| Application | Home Appliances, BOATS, Electric Power Systems, Solar Energy Storage Systems, Telecom /UPS/Solar Energy Storage | Product name | Lithium Battery |
| Chemistry | LifePo4 | Configuration | 16S4P |
| Case Material | ABS | Enclosure Protection | IP20 |
| Short Circuit Protection | 200-400μs | Low Temperature Cut-off Charge | 32℉[0℃][Customized] |
| High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | Shipping Classification | UN3480,CLASS9 |
| Chargeable | Yes |
Discharge Specifications | Charge Specifications | ||||
Maximum Continuous Discharge Current | 100A | Recommend Charge Current | 5A-40A | ||
Peak Discharge Current | ≤150A | Maximum Charge Current | 50A | ||
BMS Discharge Current Cut-off | 130A±20A [90±10ms] | Recommed Charge Voltage | 52.5-54V | ||
Recommend Low Voltage Disconnect | 42V | BMS Charge Voltage Cut-off | 54V[3.75±0.1V] | ||
BMS Discharge Voltage Cut-off | 42V[2.8±0.08 vpc] [100±50ms] | Reconnect Voltage | 51.8V[3.45±0.1V] | ||
Reconnect Voltage | 10V[2.5±0.1vpc] | Balancing Voltage | 52.5V[3.5±0.025vpc] | ||
Short Circuit Protection | 200-400μs | Balancing Current | 35±5mA | ||
Temperature Specifications | ||
Discharge Temperature | -4 to 140℉[-20 to 60℃] | |
Charge Temperature | 32 to 113℉[0 to 45℃] | |
Storage Temperature | 23 to 113℉[-5 to 45℃] | |
BMS High Temperature cut-off Discharge | 149℉[65℃][Customized] | |
Reconnect Temperature | 122℉[50℃][Customized] | |
Low Temperature Cut-off Charge | 32℉[0℃][Customized] | |
High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | |
