Pine Energy (Shenzhen)co., Ltd is engaged in offering a broad assortment of Lithium Ion Batteries. Technological innovation promotes products to achieve an invincible position in fierce competition. After assessing the needs of customers and the market, we have successfully made Solar System Deep Cycle Storage Batteries Lifepo4 Lithium Battery 12v 200 Ah Lithium Ion Battery have some wanderful advantages, all of which can help make it stand out in the market. Moreover, its appearance is highly emphasized as well. Our creative designers make the product unique in its appearance by keeping close up with the latest industry trends.
| Brand Name | PINE | Model Number | PN-LP-1250 |
| Battery Size | 18650 | Place of Origin | China |
| Weight | 7KG | Warranty | 5years |
| Anode Material | LFP | Application | Solar Energy Storage Systems |
| Product name | Lithium Battery | Chemistry | LifePo4 |
| Configuration | 4S1P | Case Material | ABS |
| Enclosure Protection | IP55 | Short Circuit Protection | 200-400μs |
| Low Temperature Cut-off Charge | 32℉[0℃][Customized] | High Temperature Cut-off Charge | 129.2℉[54℃][Customized] |
| Shipping Classification | UN3480,CLASS9 | Efficiency | 99% |
| Chargeable | Yes | Certification | CE[Battery], UN38.3[Battery] IEC62133[cell] |
Electrical Specification | Mechanical Specifications | ||||
Nominal Voltage: | 12.8V | Dimensions: | 198*166*170mm | ||
Nominal Capacity | 50Ah | Weight: | 7KG | ||
Capacity @20A | 150min | Terminal Type: | M8/M6 | ||
Energy | 640Wh | Case Material: | ABS | ||
Resistance | ≤30mΩ @ 50% SOC | Enclosure Protection: | IP55 | ||
Efficiency: | 99% | Cell Type: | Prismatic | ||
Self Discharge | ≤3.5% Per Month | Chemistry: | LifePo4 | ||
Maximum Modules in series of Parallel: | 4 | Configuration: | 4S1P | ||
Discharge Specifications | Charge Specifications | ||||
Maximum Continuous Discharge Current | 50A | Recommend Charge Current | 5A-50A | ||
Peak Discharge Current | 120A≤5s | Maximum Charge Current | 100A | ||
BMS Discharge Current Cut-off | 150A±20A [2.2±1ms] | Recommed Charge Voltage | 14.2-14.6V | ||
Recommend Low Voltage Disconnect | 8.8V | BMS Charge Voltage Cut-off | 15.0V[3.75±0.1V] | ||
BMS Discharge Voltage Cut-off | 8.8V[2.2±0.08 vpc] [100±50ms] | Reconnect Voltage | 14.6V[3.65±0.1V] | ||
Reconnect Voltage | 10V[2.5±0.1vpc] | Balancing Voltage | 14.0V[3.5±0.025vpc] | ||
Short Circuit Protection | 200-400μs | Balancing Current | 35±5mA | ||
Temperature Specifications | ||
Discharge Temperature | -4 to 140℉[-20 to 60℃] | |
Charge Temperature | 32 to 113℉[0 to 45℃] | |
Storage Temperature | 23 to 95℉[-5 to 35℃] | |
BMS High Temperature cut-off Discharge | 149℉[65℃][Customized] | |
Reconnect Temperature | 122℉[50℃][Customized] | |
Low Temperature Cut-off Charge | 32℉[0℃][Customized] | |
High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | |
