Cheap Special Design Widely Used Customized Rechargeable Lithium Ion Battery Assembly Equipment Pack are superior to other similar products in terms of appearance, performance, and operation methods, and have been unanimously recognized by customers in the market, and market feedback is good.Moreover,It can meet the more and more complicated requirements from the market.
Pine Energy (Shenzhen)co., Ltd maintains stringent norms of quality to manufacture Cheap Special Design Widely Used Customized Rechargeable Lithium Ion Battery Assembly Equipment Pack. Cheap Special Design Widely Used Customized Rechargeable Lithium Ion Battery Assembly Equipment Pack has made great technological breakthroughs because technicians often hold training and technical exchanges to improve professional skills. In the future, Pine Energy (Shenzhen)co., Ltd will continue to attach importance to the cultivation of talents, continuously improve the staff's business level and professional skills, strengthen technological innovation, and continuously enhance the comprehensive competitiveness of the company, in order to achieve'building a century-old evergreen enterprise and creating a well-known international brand' Work hard for this grand goal.
Brand Name | PINE | Model Number | PN-LP-48100 |
Battery Size | 18650 | Place of Origin | China |
Warranty | 3months-1year | Anode Material | LFP |
Application | Power Tools, Home Appliances, BOATS, Golf Carts, Electric Bicycles/Scooters, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems | Product name | Litihum battery |
Capacity @50A | 120min | Energy | 4800Wh |
Resistance | ≤30mΩ @ 50% SOC | Efficiency | 99% |
Self Discharge | ≤3.5% Per Month | Maximum Modules in series of Parallel | 15 |
Dimensions(L*W*H) | 560*269*220mm | Weight | 560*269*220mm |
Terminal Type | M8/M6 |
Electrical Specification | Mechanical Specifications | ||||
Nominal Voltage | 48V | Dimensions(L*W*H): | 560*269*220mm | ||
Nominal Capacity | 100Ah | Weight: | 45KG | ||
Capacity @50A | 120min | Terminal Type: | M8/M6 | ||
Energy | 4800Wh | Case Material: | ABS | ||
Resistance | ≤30mΩ @ 50% SOC | Enclosure Protection: | IP65 | ||
Efficiency: | 99% | Cell Type: | Prismatic | ||
Self Discharge | ≤3.5% Per Month | Chemistry: | LifePo4 | ||
Maximum Modules in series of Parallel: | 15 | Configuration: | 15S1P |
Discharge Specifications | Charge Specifications | ||||
Maximum Continuous Discharge Current | 100A | Recommend Charge Current | 5A-50A | ||
Peak Discharge Current | 260A≤5s | Maximum Charge Current | 100A | ||
BMS Discharge Current Cut-off | 300A±20A [2.2±1ms] | Recommed Charge Voltage | 53.2-54.7V | ||
Recommend Low Voltage Disconnect | 33.0V | BMS Charge Voltage Cut-off | 56.25V[3.75±0.1V] | ||
BMS Discharge Voltage Cut-off | 33.0V[2.2±0.08 vpc] [100±50ms] | Reconnect Voltage | 54.75V[3.65±0.1V] | ||
Reconnect Voltage | 37.5V[2.5±0.1vpc] | Balancing Voltage | 52.5V[3.5±0.025vpc] | ||
Short Circuit Protection | 200-400μs | Balancing Current | 35±5mA |
Temperature Specifications | Compliance Specifications | ||||
Discharge Temperature | -4 to 140℉[-20 to 60℃] | Certifications | CE[Battery], UN38.3[Battery] IEC62133[cell] | ||
Charge Temperature | 32 to 113℉[0 to 45℃] | ||||
Storage Temperature | -4 to 113℉[-20 to 45℃] | ||||
BMS High Temperature cut-off Discharge | 149℉[65℃][Customized] | ||||
Reconnect Temperature | 122℉[50℃][Customized] | ||||
Low Temperature Cut-off Charge | 32℉[0℃][Customized] | ||||
High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | Shipping Classification | UN3480,CLASS9 |
