Pine Energy (Shenzhen)co., Ltd is always dedicated to the research and development, production and sale of the M8/m6 Sell Like Hot Cakes And Durable Lithium-ion Battery Pack. Technology is the core competitiveness of a company. Since established, we have been researching and developing high-level technologies to make sure highly efficient manufacturing process.It covers a wide range and is commonly seen in the application field(s) of Lithium Ion Batteries. Thanks to the multiple characteristics that have been tested by our QC inspectors,solar inverter, lithium ion battery , DC/AC power inverter , outdoor portable station, Car jump starter has a wide application in different fields mainly including Ungrouped.We hold a firm belief that the broad application of the product will drive the industry to develop and advance rapidly.
Brand Name | PINE | Model Number | PN-LP-12100 |
Battery Size | 18650 | Place of Origin | China |
Warranty | 3months-1year | Anode Material | LFP |
Application | Power Tools, Home Appliances, BOATS, Golf Carts, Electric Bicycles/Scooters, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems | Product name | Litihum battery |
Capacity @20A | 300min | Energy | 1280Wh |
Resistance | ≤30mΩ @ 50% SOC | Efficiency | 99% |
Self Discharge | ≤3.5% Per Month | Maximum Modules in series of Parallel | 4 |
Dimensions | 260*168*209mm | Weight | 12KG |
Terminal Type | M8/M6 |
Electrical Specification | Mechanical Specifications | ||||
Nominal Voltage | 12.8V | Dimensions | 260*168*209mm | ||
Nominal Capacity | 100Ah | Weight | 12KG | ||
Capacity @20A | 300min | Terminal Type | M8/M6 | ||
Energy | 1280Wh | Case Material | ABS | ||
Resistance | ≤30mΩ @ 50% SOC | Enclosure Protection | IP65 | ||
Efficiency: | 99% | Cell Type | Prismatic | ||
Self Discharge | ≤3.5% Per Month | Chemistry | LifePo4 | ||
Maximum Modules in series of Parallel: | 4 | Configuration | 4S1P |
Discharge Specifications | Charge Specifications | ||||
Maximum Continuous Discharge Current | 100A | Recommend Charge Current | 5A-50A | ||
Peak Discharge Current | 260A≤5s | Maximum Charge Current | 100A | ||
BMS Discharge Current Cut-off | 300A±50A [2.2±1ms] | Recommed Charge Voltage | 14.2-14.6V | ||
Recommend Low Voltage Disconnect | 8.8V | BMS Charge Voltage Cut-off | 15.0V[3.75±0.1V] | ||
BMS Discharge Voltage Cut-off | 8.8V[2.2±0.08 vpc] [100±50ms] | Reconnect Voltage | 14.6V[3.65±0.1V] | ||
Reconnect Voltage | 10V[2.5±0.1vpc] | Balancing Voltage | 14.0V[3.5±0.025vpc] | ||
Short Circuit Protection | 200-400μs | Balancing Current | 35±5mA |
Temperature Specifications | Compliance Specifications | ||||
Discharge Temperature | -4 to 140℉[-20 to 60℃] | Certifications | CE[Battery], UN38.3[Battery] IEC62133[cell] | ||
Charge Temperature | 32 to 113℉[0 to 45℃] | ||||
Storage Temperature | 23 to 113℉[-5 to 45℃] | ||||
BMS High Temperature cut-off Discharge | 149℉[65℃][Customized] | ||||
Reconnect Temperature | 122℉[50℃][Customized] | ||||
Low Temperature Cut-off Charge | 32℉[0℃][Customized] | ||||
High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | Shipping Classification | UN3480,CLASS9 |
