Pine - Custom Unique Design Hot Sale Rechargeable Lifepo4 Lithium Ion Battery Packs For Solar System Ungrouped

Technology is applied to the manufacturing process of the products.Characterized by versatile features and perfect applicability,Custom Unique Design Hot Sale Rechargeable Lifepo4 Lithium Ion Battery Packs For Solar System can be widely seen in the field(s) of Lithium Ion Batteries.

SEND INQUIRY NOW

Nominal Voltage:: 12.8V

Nominal Capacity:: 60Ah

Battery Type:: Prismatic

Customization:: Customized logo (Min. Order: 50 sets) , Customized packaging (Min. Order: 100 sets) , Graphic customization (Min. Order: 200 sets)

shipping:: Express · Ocean freight · Land freight · Air freight

SEND INQUIRY NOW

Products Details

We are specialized in manufacturing Custom Unique Design Hot Sale Rechargeable Lifepo4 Lithium Ion Battery Packs For Solar System, etc. for over many years. Manufactured following the strict management system, our Custom Unique Design Hot Sale Rechargeable Lifepo4 Lithium Ion Battery Packs For Solar System has gained a reliable quality. Before its launch, it has passed the tests based on international rules and is certified by several authorities. Pine is worth the investment for those customers seeking business opportunities. Pine Energy (Shenzhen)co., Ltd will continue to work hard to improve our capabilities in R&D strength and technologies because they are the core competitiveness of our company. We aim to provide customers with the most satisfying and cost-effective products with our full efforts.

Brand Name	PINE	Model Number	PN-LP-1260
Battery Size	18650	Place of Origin	China
Warranty	3months-1year	Anode Material	LFP
Application	Power Tools, Home Appliances, BOATS, Golf Carts, Electric Bicycles/Scooters, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems	Product name	Litihum battery
Capacity @20A	150min	Energy	640Wh
Resistance	≤30mΩ @ 50% SOC	Efficiency	99%
Self Discharge	≤3.5% Per Month	Maximum Modules in series of Parallel	4
Dimensions	229138208mm	Weight	7KG
Terminal Type	M8/M6	Chargeable	Yes
Certification	CE[Battery], UN38.3[Battery],IEC62133[cell]

Products Description

Electrical Specification			Mechanical Specifications
Nominal Voltage	12.8V	Dimensions	229138208mm
Nominal Capacity	60Ah	Weight	7KG
Capacity @20A	150min	Terminal Type	M8/M6
Energy	640Wh	Case Material	ABS
Resistance	≤30mΩ @ 50% SOC	Enclosure Protection	IP55
Efficiency:	99%	Cell Type	Prismatic
Self Discharge	≤3.5% Per Month	Chemistry	LifePo4
Maximum Modules in series of Parallel	4	Configuration	4S1P

Discharge Specifications			Charge Specifications
Maximum Continuous Discharge Current	60A	Recommend Charge Current	5A-60A
Peak Discharge Current	120A≤5s	Maximum Charge Current	100A
BMS Discharge Current Cut-off	150A±20A [2.2±1ms]	Recommed Charge Voltage	14.2-14.6V
Recommend Low Voltage Disconnect	8.8V	BMS Charge Voltage Cut-off	15.0V[3.75±0.1V]
BMS Discharge Voltage Cut-off	8.8V[2.2±0.08 vpc] [100±50ms]	Reconnect Voltage	14.6V[3.65±0.1V]
Reconnect Voltage	10V[2.5±0.1vpc]	Balancing Voltage	14.0V[3.5±0.025vpc]
Short Circuit Protection	200-400μs	Balancing Current	35±5mA

Temperature Specifications			Compliance Specifications
Discharge Temperature	-4 to 140℉[-20 to 60℃]	Certifications	CE[Battery], UN38.3[Battery] IEC62133[cell]
Charge Temperature	32 to 113℉[0 to 45℃]
Storage Temperature	23 to 95℉[-5 to 35℃]
BMS High Temperature cut-off Discharge	149℉[65℃][Customized]
Reconnect Temperature	122℉[50℃][Customized]
Low Temperature Cut-off Charge	32℉[0℃][Customized]
High Temperature Cut-off Charge	129.2℉[54℃][Customized]	Shipping Classification	UN3480,CLASS9

Product display & Application

Company Profile

Pine Energy(shenzhen)Co.,Ltd.

Pine Energy (shenzhen)Co., Ltd. Is a high-tech enterprise, specialized in R&D and manufacture of Lithium rechargeable battery,LiFePo4 battery and Intelligent flight battery for UAV and agriculture sprayer and so on.

With advanced hi-tech and equipment, Pine engerge has automatic production line and strictly controls raw material inspection,production procedure and finished product inspection. That's why more and more people choose Pine Energy as their partner in the world energy industry. Our Lithium battery products are widely used in UPS backup\ Telecom towers\Solar energy storage system\electric vehicles\AGV\Golf-cart\Street-cleaner\electric-motorcycle\solar street light\and electric tools etc. We own 4 automatic lines, 150 workers, all products are full inspection. OEM/ODM support. Our total production capacity is 1 million batteries per month.

Workshop

Certifications

FAQ

A): Do you accept small order quantity, how many it is? Answer: Yes, we accept small order quantity. even 1pc B): what's the advantage of Pine energy? Answer: Strong R& D ability and quality assurance C): Do you accept OEM/ODM? Answer: We can and be able to provide OEM / ODM service. D): How long is the warranty period? Answer:Thank you for your question.We offer 3 or 5 years as the warranty period depends on customer demand.

E): How long is the warranty period? Answer:Thank you for your question.We offer 3 or 5 years as the warranty period depends on customer demand.

F): What’s the factory production capacity Answer: 2MWH per day for the production capacity . Welcome to visit our factory and contact us if any further questions
