The Fine Quality Recycling Pine Energy Storage Solar Battery Cheap 12v 300ah Lifepo4 24v 100ah Lithium Ion Battery For Rv launched by Pine Energy (Shenzhen)co., Ltd has a clear positioning and is a product designed to solve industry pain points. The Fine Quality Recycling Pine Energy Storage Solar Battery Cheap 12v 300ah Lifepo4 24v 100ah Lithium Ion Battery For Rv enables the company to have more market share, stronger competitiveness and higher visibility. By gathering the elites in the industry together,Pine Energy (Shenzhen)co., Ltd aim to make full use of their wisdom and experience to develop and manufacture competitive products. Our great wish is to become a leading enterprise on a global scale.
| Brand Name | PINE | Model Number | PN-LP-12300 |
| Battery Size | 18650 | Place of Origin | China |
| Warranty | 3months-1year | Anode Material | LFP |
| Application | Power Tools, Home Appliances, BOATS, Golf Carts, Electric Bicycles/Scooters, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems | Product name | Lithium Battery |
| Capacity @20A | 900min | Energy | 3840Wh |
| Resistance | ≤30mΩ @ 50% SOC | Efficiency | 99% |
| Self Discharge | ≤3.5% Per Month | Maximum Modules in series of Parallel | 4 |
| Dimensions(L*W*H) | 520*268*220mm | Weight | 28KG |
| Terminal Type | M8 | Chargeable | Yes |
| Certification | CE[Battery], UN38.3[Battery],IEC62133[cell] |
Electrical Specification | Mechanical Specifications | ||||
Nominal Voltage | 12.8V | Dimensions | 520*268*220mm | ||
Nominal Capacity | 300Ah | Weight | 28KG | ||
Capacity @20A | 900min | Terminal Type | M8 | ||
Energy | 3840Wh | Case Material | ABS | ||
Resistance | ≤30mΩ @ 50% SOC | Enclosure Protection | IP55 | ||
Efficiency | 99% | Cell Type | Prismatic | ||
Self Discharge | ≤3.5% Per Month | Chemistry | LifePo4 | ||
Maximum Modules in series of Parallel | 4 | Configuration | 4S3P | ||
Discharge Specifications | Charge Specifications | ||||
Maximum Continuous Discharge Current | 100A | Recommend Charge Current | 5A-50A | ||
Peak Discharge Current | 260A≤5s | Maximum Charge Current | 100A | ||
BMS Discharge Current Cut-off | 300A±50A [2.2±1ms] | Recommed Charge Voltage | 14.2-14.6V | ||
Recommend Low Voltage Disconnect | 8.8V | BMS Charge Voltage Cut-off | 15.0V[3.75±0.1V] | ||
BMS Discharge Voltage Cut-off | 8.8V[2.2±0.08 vpc] [100±50ms] | Reconnect Voltage | 14.6V[3.65±0.1V] | ||
Reconnect Voltage | 10V[2.5±0.1vpc] | Balancing Voltage | 14.0V[3.5±0.025vpc] | ||
Short Circuit Protection | 200-400μs | Balancing Current | 35±5mA | ||
Temperature Specifications | Compliance Specifications | ||||
Discharge Temperature | -4 to 140℉[-20 to 60℃] | Certifications | CE[Battery], UN38.3[Battery] IEC62133[cell] | ||
Charge Temperature | 32 to 113℉[0 to 45℃] | ||||
Storage Temperature | 23 to 95℉[-5 to 35℃] | ||||
BMS High Temperature cut-off Discharge | 149℉[65℃][Customized] | ||||
Reconnect Temperature | 122℉[50℃][Customized] | ||||
Low Temperature Cut-off Charge | 32℉[0℃][Customized] | ||||
High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | Shipping Classification | UN3480,CLASS9 | ||
