Lithium Ion Battery
Pine is a professional solar product supplier, lithium ion battery manufacturer and solar energy system factory in China.
Language
Pine is a professional solar product supplier, lithium ion battery manufacturer and solar energy system factory in China.
Everyone needs Best Selling High Quality Durable Using Lithium Ion Batteries Manufacturing Plant Charger, and we can offer you the best quality product of the world. Our professional engineers applied technology to product development.The product can be used in a wide range of applications like Lithium Ion Batteries requiring very high quality. Under the leadership of our company's board of directors, Pine Energy (Shenzhen)co., Ltd have constantly upgraded our technologies and introduced high-end machines to continuously drive the market trend and improve product quality so as to satisfy every customer. Our aim is to become one of the most trustworthy enterprises in the market.
| Brand Name | PINE | Model Number | PN-LP-12300 |
| Battery Size | 18650 | Place of Origin | China |
| Warranty | 3months-1year | Anode Material | LFP |
| Application | Power Tools, Home Appliances, BOATS, Golf Carts, Electric Bicycles/Scooters, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems | Product name | Lithium Battery |
| Capacity @20A | 900min | Energy | 3840Wh |
| Resistance | ≤30mΩ @ 50% SOC | Efficiency | 99% |
| Self Discharge | ≤3.5% Per Month | Maximum Modules in series of Parallel | 4 |
| Dimensions(L*W*H) | 520*268*220mm | Weight | 28KG |
| Terminal Type | M8 | Chargeable | Yes |
| Certification | CE[Battery], UN38.3[Battery],IEC62133[cell] |
Electrical Specification | Mechanical Specifications | ||||
Nominal Voltage | 12.8V | Dimensions | 520*268*220mm | ||
Nominal Capacity | 300Ah | Weight | 28KG | ||
Capacity @20A | 900min | Terminal Type | M8 | ||
Energy | 3840Wh | Case Material | ABS | ||
Resistance | ≤30mΩ @ 50% SOC | Enclosure Protection | IP55 | ||
Efficiency | 99% | Cell Type | Prismatic | ||
Self Discharge | ≤3.5% Per Month | Chemistry | LifePo4 | ||
Maximum Modules in series of Parallel | 4 | Configuration | 4S3P | ||
Discharge Specifications | Charge Specifications | ||||
Maximum Continuous Discharge Current | 100A | Recommend Charge Current | 5A-50A | ||
Peak Discharge Current | 260A≤5s | Maximum Charge Current | 100A | ||
BMS Discharge Current Cut-off | 300A±50A [2.2±1ms] | Recommed Charge Voltage | 14.2-14.6V | ||
Recommend Low Voltage Disconnect | 8.8V | BMS Charge Voltage Cut-off | 15.0V[3.75±0.1V] | ||
BMS Discharge Voltage Cut-off | 8.8V[2.2±0.08 vpc] [100±50ms] | Reconnect Voltage | 14.6V[3.65±0.1V] | ||
Reconnect Voltage | 10V[2.5±0.1vpc] | Balancing Voltage | 14.0V[3.5±0.025vpc] | ||
Short Circuit Protection | 200-400μs | Balancing Current | 35±5mA | ||
Temperature Specifications | Compliance Specifications | ||||
Discharge Temperature | -4 to 140℉[-20 to 60℃] | Certifications | CE[Battery], UN38.3[Battery] IEC62133[cell] | ||
Charge Temperature | 32 to 113℉[0 to 45℃] | ||||
Storage Temperature | 23 to 95℉[-5 to 35℃] | ||||
BMS High Temperature cut-off Discharge | 149℉[65℃][Customized] | ||||
Reconnect Temperature | 122℉[50℃][Customized] | ||||
Low Temperature Cut-off Charge | 32℉[0℃][Customized] | ||||
High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | Shipping Classification | UN3480,CLASS9 | ||
