Pine is a professional solar product supplier, lithium ion battery manufacturer and solar energy system factory in China.
Language
Pine is a professional solar product supplier, lithium ion battery manufacturer and solar energy system factory in China.
Our professional employees are skilled at utilizing technical resources. By utilizing technology, we ensure the product manufacturing process goes efficiently.In the application field(s) of Lithium Ion Batteries, 48v 50ah Lifepo4 Lithium Ion Battery Pack Solar Energy Storage System Battery With Smart Bms can play out its greatest effect.
Pine Energy (Shenzhen)co., Ltd keeps introducing technology to manufacture 48v 50ah Lifepo4 Lithium Ion Battery Pack Solar Energy Storage System Battery With Smart Bms. By accurately grasping the pain points of customers, the 48v 50ah Lifepo4 Lithium Ion Battery Pack Solar Energy Storage System Battery With Smart Bms developed by us has been supported and praised by the majority of customers in the market. Since established, Pine Energy (Shenzhen)co., Ltd have always been in strict compliance with international standards and high ethical standards, thus offering customers highly reliable products. We have always been following the business principle of 'honesty & integrity', which ensures that the most credible services are delivered to every customer.
| Brand Name | PINE | Model Number | PN1000C |
| Battery Size | 18650 | Place of Origin | China |
| Weight | 32KG | Storage Type | storage battery |
| Warranty | 5years | Anode Material | LFP |
| Application | Home Appliances, BOATS, Electric Power Systems, Solar Energy Storage Systems, Telecom /UPS/Solar Energy Storage | Product name | Lithium Battery |
| Chemistry | LifePo4 | Configuration | 16S4P |
| Case Material | ABS | Enclosure Protection | IP20 |
| Short Circuit Protection | 200-400μs | Low Temperature Cut-off Charge | 32℉[0℃][Customized] |
| High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | Shipping Classification | UN3480,CLASS9 |
| Chargeable | Yes | Certification | CE[Battery], UN38.3[Battery] IEC62133[cell] |
Discharge Specifications | Charge Specifications | ||||
Maximum Continuous Discharge Current | 50A | Recommend Charge Current | 5A-40A | ||
Peak Discharge Current | ≤150A | Maximum Charge Current | 50A | ||
BMS Discharge Current Cut-off | 130A±20A [90±10ms] | Recommed Charge Voltage | 52.5-54V | ||
Recommend Low Voltage Disconnect | 42V | BMS Charge Voltage Cut-off | 54V[3.75±0.1V] | ||
BMS Discharge Voltage Cut-off | 42V[2.8±0.08 vpc] [100±50ms] | Reconnect Voltage | 51.8V[3.45±0.1V] | ||
Reconnect Voltage | 10V[2.5±0.1vpc] | Balancing Voltage | 52.5V[3.5±0.025vpc] | ||
Short Circuit Protection | 200-400μs | Balancing Current | 35±5mA | ||
Temperature Specifications | ||
Discharge Temperature | -4 to 140℉[-20 to 60℃] | |
Charge Temperature | 32 to 113℉[0 to 45℃] | |
Storage Temperature | 23 to 113℉[-5 to 45℃] | |
BMS High Temperature cut-off Discharge | 149℉[65℃][Customized] | |
Reconnect Temperature | 122℉[50℃][Customized] | |
Low Temperature Cut-off Charge | 32℉[0℃][Customized] | |
High Temperature Cut-off Charge | 129.2℉[54℃][Customized] | |
